The Vulcan Seals Type 10 is a resilient, rubber diaphragm mounted parallel spring seal design with self-adjusting head to accommodate minor shaft misalignment and run-out.

The seal drive is provided by the diaphragm bellows tightly gripping the shaft and providing positive drive to the seal head and sealing face. The Vulcan Seals diaphragm seal designs are bi-directional "pusher" seals that minimise shaft fretting as the spring is constantly providing energising force to the shaft contact point and sealing face.

Supplied with a Vulcan Seals Type 20 boot-mounted stationary to suit common metric and imperial UK and European extended length seal chambers.

Why Choose the Vulcan Seals Type 10?

• Proficient diaphragm bellows design with dimensions to suit common UK metric or imperial extended length seal chambers.
• Boot mounted stationary provides maximum elastomer sealing contact to the housing surface.
• Base plate fitted at the spring drive end provides firm contact against a shaft step or circlip that sets the seal operating height. This component can be removed if not required.
• A widely utilised mechanical seal type highly suited to general light to medium duties and capable of long service life.

The Vulcan Seals Type 24S is a resilient, rubber diaphragm-mounted parallel spring seal design with a self-adjusting head to accommodate minor shaft misalignment and run-out.

The seal drive is provided by the diaphragm bellows tightly gripping the shaft and providing positive drive to the seal head and sealing face. The Vulcan Seals diaphragm seal designs are bi-directional "pusher" seals that minimise shaft fretting as the spring is constantly providing energising force to the shaft contact point and sealing face.

Supplied with a Vulcan Seals Type 24.DINS 'O'-ring-mounted stationary without anti-rotation provision, the Vulcan Seals Type 24S is fully DIN24960/En12756 L1K dimension compatible.

Why Choose the Vulcan Seals Type 24S?

• Proficient diaphragm bellows design fully compliant to DIN24960/En12756 L1K dimensions to suit common European metric seal chambers.
• 'O'-ring stationary without anti-rotation provision combines sealing performance with ease of installation.
• Base plate fitted at the spring drive end provides firm contact against a shaft step or circlip that sets the seal operating height. This component can be removed if not required.
• A widely utilised mechanical seal type highly suited to general light to medium duties and capable of long service life.

The Vulcan Seals Type 24L is a resilient, rubber diaphragm mounted parallel spring seal design with self-adjusting head to accomodate minor shaft misalignment and run-out.

The seal drive is provided by the diaphragm bellows tightly gripping the shaft and providing positive drive to the seal head and sealing face. The Vulcan Seals diaphragm seal designs are bi-directional "pusher" seals that minimise shaft fretting as the spring is constantly providing energising force to the shaft contact point and sealing face.

Supplied with a Vulcan Seals Type 24.DINL 'O'-ring-mounted stationary with anti rotation provision, the Vulcan Seals Type 24L is fully DIN24960/En12756 L1K dimension compatible.

Why Choose the Vulcan Seals Type 24L?

• Proficient diaphragm bellows design fully compliant to DIN24960/En12756 L1K dimensions to suit common European metric seal chambers.
• 'O'-ring stationary with anti-rotation provision provides security in high-torque applications such as viscous or high solids medias.
• The base plate fitted at the spring drive end provides firm contact against a shaft step or circlip that sets the seal's operating height. This component can be removed if not required.
• A widely utilised mechanical seal type highly suited to general light to medium duties and capable of long service life.

The Vulcan Seals Type 24 is a resilient, rubber diaphragm mounted parallel spring seal design with self-adjusting head to accomodate minor shaft misalignment and run-out.

The seal drive is provided by the diaphragm bellows tightly gripping the shaft and providing positive drive to the seal head and sealing face. The Vulcan Seals diaphragm seal designs are bi-directional "pusher" seals that minimise shaft fretting as the spring is constantly providing energising force to the shaft contact point and sealing face.

Supplied with a Vulcan Seals Type 24 boot-mounted stationary the Vulcan Seals Type 24 is fully DIN24960/En12756 L1K dimension compatible.

Why Choose the Vulcan Seals Type 24?

• Proficient diaphragm bellows design fully compliant to DIN24960/En12756 L1K dimensions to suit common European metric seal chambers.
• Boot-mounted stationary provides maximum elastomer sealing contact to the housing surface.
• The base plate fitted at the spring drive end provides firm contact against a shaft step or circlip that sets the seal's operating height. This component can be removed if not required.
• A widely utilised mechanical seal type highly suited to general light to medium duties and capable of long service life.

The Vulcan Seals Type 226 is a resilient, rubber diaphragm-mounted parallel spring seal design with a self-adjusting head to accommodate minor shaft misalignment and run-out.

The seal drive is provided by the diaphragm bellows tightly gripping the shaft and providing positive drive to the seal head and sealing face. The Vulcan Seals diaphragm seal designs are bi-directional "pusher" seals that minimise shaft fretting as the spring is constantly providing energising force to the shaft contact point and sealing face.

Supplied with a Vulcan Seals Type 226 boot-mounted stationary to suit common compact Asian market metric dimension seal chambers.

Why Choose the Vulcan Seals Type 226?

• Proficient diaphragm bellows design with dimensions to suit common Asian market compact length metric seal chambers.
• Boot-mounted stationary provides maximum elastomer sealing contact to the housing surface.
• The base plate fitted at the spring drive end provides firm contact against a shaft step or circlip that sets the seal's operating height. This component can be removed if not required.
• A widely utilised mechanical seal type highly suited to general light to medium duties and capable of long service life.

The Vulcan Seals Type U22 is a resilient, rubber diaphragm-mounted parallel spring seal design with a self-adjusting head to accommodate minor shaft misalignment and run-out.

The seal drive is provided by the diaphragm bellows tightly gripping the shaft and providing positive drive to the seal head and sealing face. The Vulcan Seals diaphragm seal designs are bi-directional "pusher" seals that minimise shaft fretting as the spring is constantly providing energising force to the shaft contact point and sealing face.

Supplied with a Vulcan Seals Type 11 boot-mounted stationary to suit common USA ANSI imperial extended-length seal chambers.

Why Choose the Vulcan Seals Type U22?

• Proficient diaphragm bellows design with dimensions to suit common USA ANSI extended-length imperial seal chambers.
• Boot-mounted stationary provides maximum elastomer sealing contact to the housing surface.
• The base plate fitted at the spring drive end provides firm contact against a shaft step or circlip that sets the seal's operating height. This component can be removed if not required.
• A widely utilised mechanical seal type highly suited to general light to medium duties and capable of long service life.

The Vulcan Seals Type U11J is a resilient, rubber diaphragm-mounted parallel spring seal design with a self-adjusting head to accommodate minor shaft misalignment and run-out.

The seal drive is provided by the diaphragm bellows tightly gripping the shaft and providing positive drive to the seal head and sealing face. The Vulcan Seals diaphragm seal designs are bi-directional "pusher" seals that minimise shaft fretting as the spring is constantly providing energising force to the shaft contact point and sealing face.

Supplied with a Vulcan Seals Type 31 'O'-ring-mounted stationary to suit common USA ANSI imperial regular-length seal chambers.

Why Choose the Vulcan Seals Type U11J?

• Proficient diaphragm bellows design with dimensions to suit common USA ANSI regular-length seal chambers.
• 'O'-ring stationary with anti-rotation provision provides security in high-torque applications such as viscous or high solids medias.
• The base plate fitted at the spring drive end provides firm contact against a shaft step or circlip that sets the seal's operating height. This component can be removed if not required.
• A widely utilised mechanical seal type highly suited to general light to medium duties and capable of long service life.

The Vulcan Seals Type U11 is a resilient, rubber diaphragm-mounted parallel spring seal design with a self-adjusting head to accommodate minor shaft misalignment and run-out.

The seal drive is provided by the diaphragm bellows tightly gripping the shaft and providing positive drive to the seal head and sealing face. The Vulcan Seals diaphragm seal designs are bi-directional "pusher" seals that minimise shaft fretting as the spring is constantly providing energising force to the shaft contact point and sealing face.

Supplied with a Vulcan Seals Type 11 boot-mounted stationary to suit common USA ANSI imperial regular-length seal chambers.

Why Choose the Vulcan Seals Type U11?

• Proficient diaphragm bellows design with dimensions to suit common USA ANSI regular-length imperial seal chambers.
• Boot-mounted stationary provides maximum elastomer sealing contact to the housing surface.
• The base plate fitted at the spring drive end provides firm contact against a shaft step or circlip that sets the seal's operating height. This component can be removed if not required.
• A widely utilised mechanical seal type highly suited to general light to medium duties and capable of long service life.

The Vulcan Seals Type 22J is a resilient, rubber diaphragm-mounted parallel spring seal design with a self-adjusting head to accommodate minor shaft misalignment and run-out.

The seal drive is provided by the diaphragm bellows tightly gripping the shaft and providing positive drive to the seal head and sealing face. The Vulcan Seals diaphragm seal designs are bi-directional "pusher" seals that minimise shaft fretting as the spring is constantly providing energising force to the shaft contact point and sealing face.

Supplied with a Vulcan Seals Type 31 'O'-ring stationary with anti-rotation provision suitable for common metric and imperial USA market extended-length seal chambers.

Why Choose the Vulcan Seals Type 22J?

• Proficient diaphragm bellows design with dimensions to suit common USA metric or imperial extended-length seal chambers.
• 'O'-ring stationary with anti-rotation provision provides security in high-torque applications such as viscous or high solids medias.
• The base plate fitted at the spring drive end provides firm contact against a shaft step or circlip that sets the seal's operating height. This component can be removed if not required.
• A widely utilised mechanical seal type highly suited to general light to medium duties and capable of long service life.

The Vulcan Seals Type 20H is a resilient, rubber diaphragm mounted parallel spring seal design with self-adjusting head to accommodate minor shaft misalignment and run-out.

The seal drive is provided by the diaphragm bellows tightly gripping the shaft and providing positive drive to the seal head and sealing face. The Vulcan Seals diaphragm seal designs are bi-directional "pusher" seals that minimise shaft fretting as the spring is constantly providing energising force to the shaft contact point and sealing face.

Supplied with a Vulcan Seals Type 21 'O'-ring stationary with anti-rotation provision suitable for common metric and imperial UK and European regular length seal chambers.

Why Choose the Vulcan Seals Type 20H?

• Proficient diaphragm bellows design with dimensions to suit common UK metric or imperial regular length seal chambers.
• 'O'-ring stationary with anti-rotation provision provides security in high-torque applications such as viscous or high solids medias.
• The base plate fitted at the spring drive end provides firm contact against a shaft step or circlip that sets the seal operating height. This component can be removed if not required.
• A widely utilised mechanical seal type highly suited to general light to medium duties and capable of long service life.

The Vulcan Seals Type 22 is a resilient, rubber diaphragm-mounted parallel spring seal design with a self-adjusting head to accommodate minor shaft misalignment and run-out.

The seal drive is provided by the diaphragm bellows tightly gripping the shaft and providing positive drive to the seal head and sealing face. The Vulcan Seals diaphragm seal designs are bi-directional "pusher" seals that minimise shaft fretting as the spring is constantly providing energising force to the shaft contact point and sealing face.

Supplied with a Vulcan Seals Type 11 boot-mounted stationary to suit common metric and imperial USA market extended-length seal chambers.

Why Choose the Vulcan Seals Type 22?

• Proficient diaphragm bellows design with dimensions to suit common USA metric or imperial extended-length seal chambers.
• Boot-mounted stationary provides maximum elastomer sealing contact to the housing surface.
• The base plate fitted at the spring drive end provides firm contact against a shaft step or circlip that sets the seal's operating height. This component can be removed if not required.
• A widely utilised mechanical seal type highly suited to general light to medium duties and capable of long service life.

The Vulcan Seals Type 11 is a resilient, rubber diaphragm mounted parallel spring seal design with self-adjusting head to accommodate minor shaft misalignment and run-out.

The seal drive is provided by the diaphragm bellows tightly gripping the shaft and providing positive drive to the seal head and sealing face. The Vulcan Seals diaphragm seal designs are bi-directional "pusher" seals that minimise shaft fretting as the spring is constantly providing energising force to the shaft contact point and sealing face.

Supplied with a Vulcan Seals Type 11 boot-mounted stationary to suit common metric and imperial USA market regular length seal chambers.

Why Choose the Vulcan Seals Type 11?

• Proficient diaphragm bellows design with dimensions to suit common USA metric or imperial regular length seal chambers.
• Boot mounted stationary provides maximum elastomer sealing contact to the housing surface.
• The base plate fitted at the spring drive end provides firm contact against a shaft step or circlip that sets the seal operating height. This component can be removed if not required.
• A widely utilised mechanical seal type highly suited to general light to medium duties and capable of long service life.

The Vulcan Seals Type 11J is a resilient, rubber diaphragm mounted parallel spring seal design with self-adjusting head to accommodate minor shaft misalignment and run-out.

The seal drive is provided by the diaphragm bellows tightly gripping the shaft and providing positive drive to the seal head and sealing face. The Vulcan Seals diaphragm seal designs are bi-directional "pusher" seals that minimise shaft fretting as the spring is constantly providing energising force to the shaft contact point and sealing face.

Supplied with a Vulcan Seals Type 31 'O'-ring stationary with anti-rotation provision suitable for common metric and imperial USA market regular length seal chambers.

Why Choose the Vulcan Seals Type 11J?

• Proficient diaphragm bellows design with dimensions to suit common USA metric or imperial regular length seal chambers.
• 'O'-ring stationary with anti-rotation provision provides security in high-torque applications such as viscous or high solids medias.
• The base plate fitted at the spring drive end provides firm contact against a shaft step or circlip that sets the seal operating height. This component can be removed if not required.
• A widely utilised mechanical seal type highly suited to general light to medium duties and capable of long service life.

The Vulcan Seals Type 20 is a resilient, rubber diaphragm mounted parallel spring seal design with self-adjusting head to accommodate minor shaft misalignment and run-out.

The seal drive is provided by the diaphragm bellows tightly gripping the shaft and providing positive drive to the seal head and sealing face. The Vulcan Seals diaphragm seal designs are bi-directional "pusher" seals that minimise shaft fretting as the spring is constantly providing energising force to the shaft contact point and sealing face.

Supplied with a Vulcan Seals Type 20 boot-mounted stationary to suit common metric and imperial UK and European regular length seal chambers.

Why Choose the Vulcan Seals Type 20?

• Proficient diaphragm bellows design with dimensions to suit common UK metric or imperial extended length seal chambers.
• Boot mounted stationary provides maximum elastomer sealing contact to the housing surface.
• The base plate fitted at the spring drive end provides firm contact against a shaft step or circlip that sets the seal operating height. This component can be removed if not required.
• A widely utilised mechanical seal type highly suited to general light to medium duties and capable of long service life.
